Sensor element type: Fully sealed sensor cell with gas-specific
gel electrolyte with hydrophobic filter.
Detected gas: Non-visible smoke, smoldering fire, CO+ gas radicals
Measurement range: 0-300 ppm
Accuracy: 13 ppm
Resolution: 0.5 ppm
Repeatability: <15% FS
T90 Time: 50 seconds (response time s 30 seconds)
Zero-point variation: 14 ppm
Calibration drift: < 10.4% FS signal per month
Sensor Life Time: > 6 years (if calibrated every one year)
Calibration interval: 12 months
Power supply: +16-29 VDC with reverse polarity diode protection
Power consumption: 22mA max. (0.5VA @ +24VDC)
Analog signal output: Linear proportional 4-20mA current loop
Output load: s 500 for current signal
Operating temperature range: -15 °C to +50°C
Humidity range: 10-95% RH (non-condensing)
Pressure range: Atmospheric +20%
Wire Connection: Spring loaded terminals
Mounting: Wall mounting (No Orientation Problem)
Mounting Height: Depending on the site condition
Sensor cartridge Dimensions: 38 mm (L) x M25 mounting dia
Sensor cartridge Weight: 30 g
Sensor Cartridge MOC: Polycarbonate (IP65)
D: Fully gasketed Polycarbonate, IP65, UL 94: V2, weight: 0.15 Kg
K:D Housing with Duct Kit, weight: 0.1 Kg
FLP: Flameproof (IP 66-11 2G Ex db IIC T6 Gb), 95×75 mm dia
Optional Specification: Relays, Modbus output, Display & Keypad
